Description
Precision PTE 5130 CEA Turbo
This popular 51mm turbo is precisions small frame T25 design, rated for 460hp depending on the application. Exclusive CEA (Competition Engineered Aerodynamics) compressor wheel machined from a 2618-aluminum forging. Liquid-cooled, dual ceramic ball-bearing center housing rotating assembly (CHRA). Wastegate Not Included, Optional. Ball Bearing Only.
Compressor Specifications
- Compressor Wheel Exducer: 2.520″
- Compressor Wheel Inducer: 2.008″
- Compressor Housing Connections:
- Inlet: 2.8″ Hose Coupler (CCB), 3.0″ Hose Coupler (CCE)
- Outlet: 2.0″ Hose Coupler (CCB and CCE)
Turbine Specifications
- Turbine Wheel: 56.5mm – 84 Trim
- Housing Size and A/R ratio: PT5130 CEA is available in nine (9) different turbine housing configurations:
- T25 Inlet, T25 Discharge Outlet 0.64 A/R
- T25 Inlet, T25 Discharge Outlet 0.86 A/R
