80mm Precision Pro Mod Gen2 X275
The 80mm Gen2 ProMod turbo is proven to be a dominant turbocharger for heavy-hitter X275 drag racing competitors. Designed specifically for use in the Drag Radial Class, this 80mm inducer turbo is rated for 1400hp per turbo. The GT47 compressor housing has a 6″ inlet to house the exclusive 130mm CEA (Competition Engineered Aerodynamics) compressor wheel machined from a 2618-aluminum forging.
Compressor Specifications
- Compressor Wheel Exducer: 130mm
- Compressor Wheel Inducer: 80mm
- Compressor Housing Connections:
- Inlet: 6″ Hose Coupler (GT47 Compressor Cover)
- Outlet: 3.5″ V-Band (GT47 Compressor Cover)
Turbine Specifications
- Turbine Wheel Exducer: 103.38mm
- Turbine Wheel Inducer: 111.76mm
- Housing Size and A/R ratio: Gen2 Pro Mod 80 X275 Drag Radial Class is available in five (5) different turbine housing configurations:
- Stainless Steel V-Band Inlet, V-Band Outlet 1.15 A/R
- T5 Open Inlet, V-Band Outlet 1.00 A/R
- T5 Open Inlet, V-Band Outlet 1.12 A/R
- T5 Open Inlet, V-Band Outlet 1.24 A/R
- T5 Open Inlet, V-Band Outlet 1.40 A/R
