76mm Precision PT7685 Sportsman Gen2 CEA Turbo

Precision’s Gen2 7685 is a proven turbo for competitive Drag Racing dominance.  Rated for 1350hp depending on the application, it is available as a highly durable and fast spooling Ball Bearing CHRA Only.  Exclusive CEA‚® (Competition Engineered Aerodynamics) compressor wheel machined from a 2618-aluminum forging with a 102.3mm exducer and 76.7mm inducer.

• Compressor Wheel Exducer: 102.36mm
• Compressor Wheel Inducer: 76.71mm
• Compressor Housing Connections:
  • Inlet: 5″ Hose Coupler (GT42 Compressor Cover)
  • Outlet: 3.5″ V-Band (GT42 Compressor Cover)
• Turbine Wheel Exducer: 84.7mm
• Turbine Wheel Inducer: 89.54mm

The Precision Gen 2 PT7685 Sportsman CEA Turbo is available in six (6) different turbine housing configurations:

• GEN2 7685: Stainless Steel V-Band In/Out 1.15 A/R (22207219829)
• GEN2 7685: Stainless Steel V-Band In/Out 1.28 A/R (22207219839)
• GEN2 PT7685 Sportsman: T4 Divided Inlet, V-Band Outlet 0.98 A/R (22209219319)
• GEN2 PT7685 Sportsman: T4 Divided Inlet, V-Band Outlet 1.12 A/R (22209219329)
• GEN2 PT7685 Sportsman: T4 Divided Inlet, V-Band Outlet 1.28 A/R (22209219339)
• GEN2 PT7685 Sportsman: Sportsman Stainless V-Band In/Out 1.00 A/R (22209219819)
• GEN2 PT7685 Sportsman: Sportsman Stainless V-Band In/Out 1.15 A/R (22209219829)
• GEN2 PT7685 Sportsman: Sportsman Stainless V-Band In/Out 1.28 A/R (22209219839)
